Co2 Separate Glass Laser marking Machine Co2 laser marking system

Co2 Laser Marking Machine

1. Environmentally friendly: No need water chiller to cool, small size small occupation, can be easily installed in many places.

2. Permanent marking: It won’t fade, run or become less discernable as time passes like traditional marking including ink jet, hand engraving, dot-peen marking.

3. Cost-effective: No maintenance during the 80,000 hours working life. One machine can be used in many different materials & industry. Marking software c/w machine. Minimal part replacement

4. High efficiency and High Precision: Computer operated, the Marking speed is up to 7000mm/s and Minimum line width is up to 0.01mm..

5. Full supporting: Warranty two years. Full operator training. Our engineers providing a solution according to your application. Engineers available service machinery overseas.

6. High quality: CE & ISO & BV & FDA approved, imported core spare parts like German IPG fiber laser.

Inquire Now Next Product

product details
video

Features:

Product Hightlights

1.Laser source David/Synrad/Coherent for your choice 2.Control card Beijing JCZ brand EZCAD software 3.Galvanometer High speed.high precision scaniab or sino-galvo brand you can choose 4.Power Supply Taiwan Meanwell 5.Filed Lens Singapore Wavelength 6.Double Red Lights posit the exact marking area for work piece 7.Lifting Pillar by hand or electric two options 8.Button One for main power,one for emergency button ,one for laser power

Specifications

Graphic Format Supported:AI, BMP, DST, DWG, DXF, DXP, LAS, PLT

Application:Laser Marking

Condition:New

CNC or Not:Yes

Cooling Mode:Air Cooling

Control Software:EZCAD

Place of Origin:Hubei, China (Mainland)

Brand Name:OV Laser

Certification: CE, ISO, FDA

Warranty:2 years

Laser Source:Raycus/IPG/JPT/MAX (optional)

Marking Area:110*110/175*175/200*200/300*300mm

Laser Wavelength:1064nm

Marking Speed:0-8000mm/s

Marking Depth:0.015-0.5mm

Applicable Material:Metal and some non-metal

Power Supply:220V+_10%, 50HZ+_5%

Laser Repetition Frequency:20-60KHZ

Field Lens:Singapore Wavelength

Co2 Separate Glass Laser marking Machine

Supply Ability

100 Set/Sets per Month Glass Laser Machine

Packaging & Delivery

There are 3 layers of package: waterproof thickening plastic bag; foam to protect from shaking; solid export wooden case.

Co2 Separate Glass Laser marking Machine

Port

wuhan/ningbo/shanghai/your port

Lead Time :

Quantity(Sets) 1-5 >5

Est. Time(days) 10 To be negotiated

Co2 Separate Glass Laser marking Machine Co2 laser marking system

Power	10W/20W/30W/60W
Laser Wavelength	1064μm
Marking Area	110mm110mm, optional 7070mm, 145145mm, 175175mm, 200200mm, 300300mm
Laser Source	Synard/CRD/DW
Marking Speed	0-8000mm/s
Minimum Line Width	0.015mm
Minimum Character	0.3mm*0.3mm
Repeated Precision	±0.003mm
Lifespan of Fiber Laser Source	80000 hours
Focus Spot Diameter	<0.01mm
System Operating Environment	WINDOWS XP/7/8
Cooling Mode	Air Cooling
Working Temperature	0℃-40℃
Voltage	220V/50Hz or 60Hz
Power	800W/1200W
