Product Hightlights
Applicable industry Electrical Engineering and Electrical part and component Mobile (Cover,battery,keyboard, I Phone Case), plastic case Jewellery(Ring,pedeant,bracelet), eyeglass, clocks and craft Building materials, PVC pipe Car industry(motor spare parts) Insturment and meters and cutting tool hardware fitting and accessory sanitary appliance food and beverage Medicine package and surgical instruments
Specifications
Graphic Format Supported: AI, BMP, DST, DWG, DXF, DXP, LAS, PLT
Application:Laser Marking
Condition:New
CNC or Not:Yes
Cooling Mode:Air Cooling
Control Software:EZCAD
Place of Origin:Hubei, China (Mainland)
Brand Name:OV Laser
Certification: CE, ISO, FDA
Warranty:3 years
Laser Source:Raycus
Marking Area: 110*110mm/ 200*200mm/300*300mm
Laser Wavelength:1064nm
Marking Speed: 7000mm/s
Applicable Material: Metal
Field Lens:Singapore Wavelength
Packaging & Delivery
There are 3 layers of package: waterproof thickening plastic bag; foam to protect from shaking; solid export wooden case.
Port
Wuhan port or any China port
Lead Time :
Quantity(Sets) 1-1 >1
Est. Time(days) 5 To be negotiated
| Model | OV SF-20 |
| Laser Power | 20w, 30w, 50w |
| Laser Source Brand | IPG/JPT/Raycus/MAX (optional) |
| Beam quality | <30um |
| Minimum Line Width | 0.015mm |
| Minimum Character | 0.2mm |
| Voltage | 220V / 50HZ / 1-PH or 110V / 60HZ / 1-PH |
| Operation Environment | Win7 / 8 / 10 (32 bit , 64 bit) |
| Cooling Mode | Air cooling--Built-in |
